safety products

Anti-collapse panels

Anti-Collapse Panels
Designed as a mesh screen to clad pallet racking, and increase safety while handling pallets and palletised items. Panels are constructed from cold-rolled angle and cold-rolled T-bar into which mesh sheets are spot-welded to give added strength and resistance to impact.
Manufactured to suit the racking bay centres, thus eliminating the need to cut and fabricate panels on site and are bolted together for added strength and rigidity.
Triangular stand-off brackets, which act as spacers between the racking and the mesh panels, can be made to suit customers’ requirements.
The intermediate brackets are reversible so that they do not interfere with the racking beams. Every installation is manufactured to fit each individual site, thus ensuring easy and fast installation time.

product specification


Angle Framework
43 x 43 x 1.2 mm
T-bar
32 x 3x x 0.7 mm
Dado Mesh Sheets
75 x 75 x 3 mm
Stand-off Bracket
75 to 350 mm deep
Standard Panel
1,245 mm high
Finish
Powder-coated to match or contrast with the racking system
safety products

Pedestrian safety barriers

Pedestrian Safety Barriers
A light duty system providing a simple and economical way to create safe pedestrian areas at ground or raised floor level, in factory or warehouse.
The recommended maximum height of rails is 1,100 mm, the recommended maximum length of rail between each post is 2,000 mm.
Height and length of rail are manufactured to suit customers’ requirements.
Single or double rails are bolted to posts, allowing individual components to be replaced easily.

product specification


Rail
Hollow section 50 x 50 x 2.5 mm
Posts
Hollow section 50 x 50 x 2.5 mm
Post tops fitted with black plastic inserts
Base Plates
150 x 50 x 10 mm
Finish
Powder-coated Yellow RAL 1018 or to customers’ requirements
safety products

Tubular barriers

Tubular Barriers
Tubular barriers are low level and heavy duty with rounded corners for protection of people and equipment.

product specification


Height
500mm or 750mm
Individual barrier length
up to 2,500mm
Maximum length with centre post
4,000mm
Finish
To customers’ requirements
safety products

Crash barriers

Crash Barriers
Our crash barriers consist of steel rails bolted to support posts, mounted on base plates, and are designed to protect machinery, racking, shelving and partitioning from damage.

product specification


Heavy Duty Steel Rail (galvanised)
312 mm deep
3.2 m lengths
Twin rail version available
Support Post
100 x 100 x 3.5 mm
Height 750 mm
Special heights can be supplied
Base Plate
200 x 200 x 10 mm
Finish
To customers’ requirements
